Valve actuator

Strega Smart Switch LoRaWAN decoder and payload format

The Strega Smart Switch is a LoRaWAN valve actuator that reports valve position, temperature and humidity. It is rated IP67, it runs on a replaceable AA battery and it works from -30 to 85 °C.

Strega Smart Switch
Official decoderDatasheetProduct page

Payload format

An uplink from the device as it arrives at the network server, and what the official decoder returns for it. Examples come from the decoder's own test cases.

Example 1 · fPort 4

Payload (hex)

33 31 38 38 32 23 63 3D 77 DB

Decoded (JSON)

{
  "Actuator": "0",
  "Ana": "null",
  "Bat": 74,
  "Cable": "0",
  "Class": "0",
  "DI0": "0",
  "DI1": "0",
  "Fraud": "0",
  "Hygro": 46.82,
  "Leak": "0",
  "Power": "0",
  "Tamper": "1",
  "Temp": 23.96,
  "counterValue": "null",
  "vt": "10"
}
FieldValue
Actuator0
Ananull
Bat74
Cable0
Class0
DI00
DI10
Fraud0
Hygro46.82
Leak0
Power0
Tamper1
Temp23.96
counterValuenull
vt10

Specifications

Manufacturer
Strega
Model
Smart Switch
Type
Valve actuator
Measures
valve position, temperature, humidity
Protection
IP67
Battery
AA (replaceable)
Operating temperature
-30 … 85 °C
LoRaWAN regions
IN865-867, EU863-870, US902-928, AS923

Connect it to Cloud Studio IoT

  1. 1

    Register the device in your network server

    Add it to The Things Stack, ChirpStack, Actility ThingPark or LORIOT with its DevEUI, JoinEUI and AppKey and the frequency plan of your region.

  2. 2

    Apply the decoder

    In The Things Stack, pick the model from the device repository and its decoder is applied for you. In ChirpStack v4, paste the official decoder as the device profile's JavaScript codec.

  3. 3

    Connect the network server to Cloud Studio IoT

    Set up the integration once per network server; every device registered there then reaches Cloud Studio IoT with its decoded values.

  4. 4

    Build dashboards and alarms

    The decoded fields become device variables for dashboards, alarms by email or SMS, and scheduled reports.

See your Strega Smart Switch on a dashboard

Start a free trial, add the device with its DevEUI and get dashboards and alarms from its next uplink.
